| Table | | Table Size | 2100 * 550mm | | Table working surface | 2100 * 550mm | | Max, table load | 2000 kgs | | X-axis Ball Screws | 1400 mm | | Y-axis Ball Screws | 520 mm | | Z-axis | 600 mm | | T-slots(Width * No. * Distance) | 18mm * 6 * 80mm | | Spindle end to table top | 180 ~ 780 mm |
|
| Spindle | | Spindle Speed | 45-1500 (12 speeds) | | Spindle Nose to Taper | NT 50 / BT 50 (opt) |
|
| ATC | | Tool storage | - | | Tool Dia. * Length (Max.) | 125 * 250 mm | | Max.tool weight | 25 kgs |
|
| Motor | | Spindle motor | 10 HP(7.5kW) | | Vice Spindle head travel | - | | Vice Spindle travel | - | | Vice Spindle motor | - | | Vice Spindle speed | - | | X,Y,Z - axis DC motor | 2 HP | | Cooling Motor | 1/6 HP(12w) | | Lubrication Motor | 0.036 HP(25w) |
|
| Feed | | Cutting feed rate | 37 ~ 1165 mm/min | | Rapid traverse rate(X,Y,Z) | 3730 mm/min |
|
| Machine Weight | | N.W./G.W. | 5800 kgs / 6400 kgs | | Machine dimensions(L*W*H) | 2800 * 2200 * 2710 mm | | Packing Size | 2800 * 2400 * 2820 mm |
|
